Introduction

Name of Contents show

Oracle APEX makes it possible to build interactive business applications using SQL and PL/SQL while also allowing developers to extend applications with JavaScript, CSS and AJAX-based processes.

In this project, I built an interactive Product Catalog and Drag-and-Drop Shopping Cart using Oracle APEX.

The application allows users to:

View products in a visual catalog
Display product images dynamically
Display product names and prices
Select products by clicking
Drag products into the shopping cart
Store selected products in an APEX Collection
Display cart contents using an Interactive Report
Remove products from the cart
Clear the entire cart
Refresh the cart dynamically without a full page reload

The final interface contains a product catalog on the left and a shopping cart/report area on the right.

1. Final Application

The final application provides a simple shopping experience:

Product Catalog → Select/Drag Product → Add to Cart → Display Cart → Remove/Clear

The catalog dynamically displays products from the AUW_PRODUCTS table. The exported APEX page uses a PL/SQL region to generate the product cards and their Base64-encoded images. f47299_page_10

Main UI Components

The application contains:

Product Catalog
Product ID item
Product cards
Product image
Product price
Shopping Cart
Interactive Report
Clear button

Drag-and-drop functionality

2. Application Architecture

The basic architecture is:

         AUW_PRODUCTS
                     │
                     ▼
             Product Catalog
                     │
          ┌──────────┴──────────┐
          │                     │
       Click                 Drag & Drop
          │                     │
          └──────────┬──────────┘
                     ▼
              P10_PRODUCT_ID
                     │
                     ▼
             ADD_TO_CART AJAX
                     │
                     ▼
             APEX_COLLECTION
                SHOPCART
                     │
                     ▼
             Interactive Report
                     │
          ┌──────────┴──────────┐
          │                     │
       Remove                 Clear

This architecture keeps the product source in the database while using an APEX Collection as a session-level shopping cart.

3. Product Catalog

The catalog is generated dynamically using PL/SQL.

The application reads products from:

AUW_PRODUCTS

and generates HTML for each product.
The important query structure is:

select
    '<div id="' || product_id || '"
           class="catdiv"
           draggable="true"
           ondragstart="drag_handle(event)">

        <div class="catalog">

            <div>

                <p class="pname">
                    ' || product_id || ' - ' || product_name || '
                </p>

                <div class="prod_img"
                     style="text-align: center">

                    <img
                        id="' || product_id || '"
                        apex_web_service.blob2clobbase64(product_image) ||
                        '" />

                    Price $' || list_price || '

                </div>

            </div>

        </div>

    </div>' dragline
from AUW_PRODUCTS;

The export confirms that the application uses APEX_WEB_SERVICE.BLOB2CLOBBASE64 to convert the product image BLOB into Base64 content for the HTML image element. f47299_page_10

This is useful when product images are stored directly inside the Oracle Database rather than on an external image server.

4. Why Use PL/SQL to Generate the Catalog?

Instead of manually creating ten HTML cards, the application generates them dynamically.

For example:

for r_products in c_products loop

    sys.htp.print(r_products.dragline);

end loop;

This means that if a new product is inserted into AUW_PRODUCTS, the catalog can automatically display it.

No additional HTML card needs to be manually created.

This is one of the advantages of combining:

Oracle Database + PL/SQL + APEX UI

5. Drag-and-Drop Functionality

The most interesting part of this application is the drag-and-drop functionality.

The page JavaScript contains three main functions:

function drop_over_handle(evt) {
    evt.preventDefault();
}

This allows the dragged element to be dropped over the target.

The drag handler stores the product ID:

function drag_handle(evt) {

    evt.dataTransfer.setData(
        "Text",
        evt.target.id
    );

}

When the product is dropped, the application retrieves the product ID:

function drop_handle(obj, evt) {

    evt.preventDefault(evt);

    var data =
        evt.dataTransfer.getData("Text");

    $x("P10_PRODUCT_ID").value = data;

    apex.server.process(
        "ADD_TO_CART",
        {
            pageItems: "#P10_PRODUCT_ID"
        }
    );

}

The exported application contains this drag/drop logic in the page-level JavaScript.

6. Click-to-Add Functionality

The application doesn’t require users to drag products.

Products can also be selected using a normal click.

$(".prodpic").click(function() {

    $("#cart").trigger("apexrefresh");

    $x("P10_PRODUCT_ID").value = this.id;

    apex.server.process(
        "ADD_TO_CART",
        {
            pageItems: "#P10_PRODUCT_ID"
        }
    );

});

This provides an alternative interaction model for users who don’t want to use drag-and-drop.

7. AJAX Process

When a product is selected, JavaScript calls the APEX On-Demand Process:

apex.server.process(
    "ADD_TO_CART",
    {
        pageItems: "#P10_PRODUCT_ID"
    }
);

The process is named:

ADD_TO_CART

The exported page defines this as an On Demand Native PL/SQL process.

8. Adding Products to APEX Collection

The shopping cart is implemented using an Oracle APEX Collection called:

SHOPCART

The process retrieves the selected product:

select p.rowid, p.*
from AUW_PRODUCTS p
where product_id = :P10_PRODUCT_ID

Then the product is added to the collection:

apex_collection.add_member(
    p_collection_name => 'SHOPCART',
    p_c001            => x.product_id,
    p_c002            => x.product_name,
    p_n001            => 1,
    p_n002            => x.list_price,
    p_n004            => x.list_price * 1,
    p_c010            => x.rowid
);

The exported application uses SHOPCART to hold selected products during the user’s session.

9. Why APEX Collection?

An APEX Collection is useful for temporary session-based data.

For a shopping cart, it provides a convenient structure:

Product ID
Product Name
Quantity
Price
Amount
ROWID

The collection does not require creating a permanent shopping-cart table just to maintain temporary session selections.

This makes it suitable for prototypes, demonstrations and applications where cart information only needs to exist during the user’s APEX session.

10. Shopping Cart Interactive Report

The shopping cart is displayed using an Oracle APEX Interactive Report.

The report reads from:

APEX_COLLECTIONS

using:

SELECT
    c001 product_id,
    c002 product_name,
    SUM(n001) quantity,
    n002 list_price,
    SUM(n004) amount,
    'REMOVE' AS remove
FROM apex_collections
WHERE collection_name = 'SHOPCART'
GROUP BY
    c001,
    c002,
    n002
ORDER BY
    TO_NUMBER(product_id);

This query is part of the exported page configuration.

11. Cart Data Structure

The collection columns are mapped as follows:

Collection	Purpose
`C001`	Product ID
`C002`	Product Name
`N001`	Quantity
`N002`	List Price
`N004`	Amount
`C010`	Product ROWID

The Interactive Report exposes Product ID, Product Name, Quantity, List Price, Amount and Remove.

12. Removing a Product

The application also provides a remove operation.

The remove request is triggered through the report column:

REMOVE

The link passes the product ID back to Page 10.

The corresponding PL/SQL process searches the collection:

select seq_id, c001
from apex_collections
where collection_name = 'SHOPCART'
and c001 = :P10_PRODUCT_ID

Then deletes the matching collection member:

apex_collection.delete_member(
    p_collection_name => 'SHOPCART',
    p_seq             => x.seq_id
);

This logic is included in the page’s remove product from cart process.

13. Clear Shopping Cart

The application also contains a Clear button.

The button submits the page and executes:

apex_collection.truncate_collection(
    'SHOPCART'
);

This removes all products from the current shopping cart.

14. Initializing the Collection

Before the page is displayed, the application checks whether the collection exists.

if not apex_collection.collection_exists(
    'SHOPCART'
) then

    apex_collection.create_or_truncate_collection(
        p_collection_name => 'SHOPCART'
    );

end if;

This prevents errors when the user interacts with the cart for the first time.

15. Custom CSS

The default APEX presentation was enhanced with custom CSS.

The product cards use:

.catalog {
    background: #ffffff;
    position: relative;

    width: 145px;
    height: 168px;

    border: 1px solid #d9e2df;
    border-radius: 7px;

    float: left;
    margin: 2px;

    overflow: hidden;

    box-shadow:
        0 2px 7px rgba(0,0,0,0.08);

    transition: all 0.25s ease;
}

A hover effect was also added:

.catalog:hover {
    transform: translateY(-3px);

    border-color: #10b981;

    box-shadow:
        0 8px 20px rgba(16,185,129,0.18);
}

The exported page contains the complete custom CSS for the catalog, product image, region header and product ID item.

16. Product Image Styling

Each image is displayed inside a defined container:

.prod_img {
    padding: 4px;

    border: 1px dashed #b9c9c3;
    border-radius: 5px;

    width: 115px;
    height: 125px;

    background: #ffffff;

    position: absolute;

    left: 50%;

    transform: translateX(-50%);
}

This creates a consistent product-card layout regardless of the original dimensions of the product image.

17. User Experience

The final interface provides two different ways to add products:

Method 1 — Drag & Drop

Product
   ↓
Drag
   ↓
Shopping Cart
   ↓
ADD_TO_CART

Method 2 — Click

Product
   ↓
Click
   ↓
Product ID
   ↓
ADD_TO_CART

This makes the application more interactive than a conventional product report.

18. Technologies Used

Technology	Purpose
Oracle APEX 26.1.3	Application development
Oracle Database	Product data
SQL	Data retrieval
PL/SQL	Dynamic catalog + cart processing
JavaScript	Drag & Drop + AJAX
APEX Collections	Session shopping cart
Interactive Report	Cart display
CSS	UI/UX customization
BLOB	Product image storage
Base64	Rendering database images

19. Key Oracle APEX Concepts Demonstrated

This project demonstrates several practical Oracle APEX concepts:

1. Native PL/SQL Region

Dynamic HTML is generated through PL/SQL.

2. APEX Collections

Temporary session-level shopping cart data.

3. On-Demand Process

AJAX request processing using:

apex.server.process()

4. Page Items

The selected product is passed through:

P10_PRODUCT_ID

5. Interactive Report

Used to display and manage shopping-cart information.

6. Dynamic Refresh

The cart region is refreshed using:

$("#cart").trigger("apexrefresh");

7. JavaScript Integration

Browser drag-and-drop functionality is integrated with APEX.

8. Custom CSS

The default APEX UI is customized to create a modern product catalog.

20. What I Learned From This Project

One of the important lessons from this project is that Oracle APEX is not limited to traditional forms and reports.

By combining:

SQL
+
PL/SQL
+
JavaScript
+
CSS
+
APEX Collections
+
AJAX

developers can create highly interactive business applications.

The project also demonstrates how database-driven applications can dynamically generate their UI instead of hardcoding every product element.

21. Possible Real-World Extensions

This concept can be extended into a complete e-commerce or business application.

Possible improvements include:

Product Search

Search by Product Name
Search by Category
Search by Product ID

Product Categories

Men
Women
Shoes
Accessories
Electronics

Quantity Management

+
-
Quantity

Cart Total

Subtotal
Tax
Discount
Grand Total

Checkout

Cart
 ↓
Customer
 ↓
Address
 ↓
Payment
 ↓
Order

Database Tables

A production version could introduce:

PRODUCTS
PRODUCT_CATEGORIES
CUSTOMERS
ORDERS
ORDER_LINES
PAYMENTS

22. Project Flow

The complete application flow can be summarized as:

   USER
               │
               ▼
        PRODUCT CATALOG
               │
       ┌───────┴────────┐
       │                │
     CLICK            DRAG
       │                │
       └───────┬────────┘
               ▼
        P10_PRODUCT_ID
               │
               ▼
       APEX.SERVER.PROCESS
               │
               ▼
          ADD_TO_CART
               │
               ▼
        AUW_PRODUCTS
               │
               ▼
        APEX_COLLECTION
           SHOPCART
               │
               ▼
       INTERACTIVE REPORT
               │
       ┌───────┴────────┐
       │                │
     REMOVE            CLEAR
       │                │
       ▼                ▼
 Delete Member    Truncate Collection

23. Conclusion

This project demonstrates how Oracle APEX can be used to create an interactive, database-driven shopping experience using native APEX functionality combined with JavaScript and CSS.

The most important aspect of the project is not the shopping cart itself. It is the integration between different Oracle APEX capabilities:

PL/SQL → Dynamic HTML → JavaScript → AJAX → APEX Collection → Interactive Report

This architecture can serve as a foundation for more advanced Oracle APEX applications such as order management systems, procurement applications, POS systems, inventory applications and e-commerce solutions.

About the Author

Zulqarnain Haider is an Oracle APEX Developer focused on Oracle APEX, SQL, PL/SQL and enterprise application development.

His technical interests include:

Oracle APEX
Oracle Database
SQL
PL/SQL
REST APIs
Oracle EBS
Enterprise Application Development
Financial Applications
UI/UX in Oracle APEX
